Legacy filtering fails on 20,000 eBGP sessions

Running 20,000 eBGP sessions behind legacy IRR filters is a losing battle. The industry's obsession with AS-set recursion has built a fragile perimeter that collapses under modern scale. It cannot stop sophisticated route leaks. We need to ditch these unwieldy allowlists for cryptographically verified origin data.

Italo Cunha's analysis via NANOG highlights the rot in IRR-based filtering. Route objects simply cannot specify prefix-length ranges efficiently. Try announcing a single /44 IPv6 block at /48 granularity. You end up maintaining 16 distinct route6 objects. That bloats prefix lists for no reason. Worse, AS-sets lock an ASN into a single policy. You cannot apply granular control across 2,000 different peers or 400 Points of Presence. The result? Loose, "allow-any" filters that leave networks wide open to mis-originations and unauthorized more-specifics.

We are moving from these broken models to RPKI ROV and ASPA validation. IRR data lacks the fidelity for modern defense. RFC 9234 automates leak prevention. Peerlock policies enforce strict boundaries. By swapping questionable provenance for cryptographically signed assertions, architects finally get precise routing policies without the burden of massive, manually generated lists.

The Critical Failure of IRR-Based Filtering in Modern Routing

AS-sets force every ASN into a single route object list. You cannot announce distinct prefixes to different neighbors. This rigidity means operators apply a uniform, often loose filter across all eBGP sessions because the database cannot distinguish intent between specific peers. Large networks managing thousands of connections find this unscalable. The mechanism lacks the resolution to define unique allowlists for individual neighbors. It creates a blanket acceptance model.

Security degrades because precise prefix-length ranges remain undefined in legacy objects. Restricting a /44 announcement to /48 granularity requires maintaining excessive object counts. You cannot enforce strict boundaries on a per-session basis.

Replacing these lists demands coordinating BGP OPEN Roles signaling. This requires bilateral support. Expect operational friction while legacy and modern systems coexist.

Relying on AS-sets introduces a systemic blind spot for targeted traffic engineering. Continuing with IRR-based filtering leaves high-volume peering points exposed to unauthorized more-specifics and route leaks.

Scaling IRR Filters Across 20,000 eBGP Sessions and 400 PoPs

Manual prefix-list generation fails catastrophically when managing 20,000 eBGP sessions across 400 Points of Presence.

The bgpq4 tool spits out oversized filters. Route objects cannot specify prefix-length ranges, forcing engineers to maintain excessive entries for granular announcements. This inefficiency compounds as networks peer with more than 2,000 different Autonomous System Numbers. Configurations become unwieldy, straining router memory and CPU cycles. Since each ASN maps to a single set of route objects, the resulting allow any policies lack precision. They cannot distinguish between specific neighbor intents. Operators trying to secure these BGP peers find that legacy IRR data offers limited validation for prefixes lacking an.

AS-sets prevent distinct prefix announcements per neighbor. This mandates a uniform security posture across diverse eBGP sessions. That blanket approach leaves large infrastructures vulnerable to unauthorized more-specifics and route leaks that precise filtering would block. The cost is measurable: router performance degrades under the weight of massive, imprecise lists while security gaps remain open. Relying on unwieldy formats from questionable provenance invites operational failure at scale.

Mis-originations and Unauthorized More-Specifics from Unverified IRR Data

Mis-originations happen when operators announce prefixes from unverified IRR data due to simple keyboard proximity errors.

Information used to construct safe pass/nopass EBGP filters often comes in unwieldy formats and from questionable provenance. Networks sit exposed to typosquatting attacks. A digit mistype on a keypad generates an invalid origin that legacy systems accept without cryptographic challenge. This vulnerability persists because route objects lack binding to specific neighbors. Any ASN can claim ownership globally. Traffic interception occurs immediately, often before manual correction happens.

Unauthorized more-specifics represent a second failure mode. Incumbents issue granular prefixes under external instruction. Scenarios exist where a government instructs their incumbent telco to kill access to specific IPs via announcements. Unlike origin validation, IRR cannot distinguish between legitimate engineering changes and coercive routing security violations. The system trusts the announcer implicitly. This enables precise censorship or hijacking without technical barriers.

Filtering based on these databases provides no assurance of actual authorization. Operators relying on this model face binary choices: block all unknowns or accept potential hijacks.

RPKI ROV and ASPA Cryptographic Verification Mechanics

RPKI ROV validates origin ASNs against signed ROAs. ASPA extends this logic to verify the entire AS path using provider authorization lists.

The mechanism relies on the binary RPKI-To-Router protocol to efficiently distribute cryptographic payloads. This avoids the latency of manual filter uploads. Route Origin Validation checks if the announcing ASN matches the signed record, rejecting mismatches immediately at the session edge. ASPA then inspects the AS path sequence, ensuring each hop aligns with the declared provider relationships stored in the RIR database. This two-stage process eliminates reliance on unwieldy IRR data that lacks cryptographic binding.

OpenBGPD simplifies adoption via a single role keyword that configures both ASPA and RFC 9234 signaling simultaneously. However, the security gain depends entirely on upstream operators publishing their provider lists. Without this data, path verification defaults to permissive acceptance. The architectural shift moves trust from manual database maintenance to automated cryptographic verification.

Fastly resolved configuration errors using the RFC 9234 OTC attribute despite limited global peer support.

This mechanism embeds a role signal directly into the BGP OPEN message. It defines relationships like customer-to-provider without external database dependencies. Operators configure their routers to advertise a specific role. This enables the remote peer to validate path legitimacy against the Gao-Rexford model immediately. Unlike legacy filters, this approach functions opportunistically. If one side lacks support, the session remains stable while the capable side enforces local policy. YYCIX successfully stopped IX-to-IX leaks using this method even when intermediate networks did not support the extension. The deployment model shifts validation from complex prefix-lists to a simple session-level negotiation that requires zero maintenance once established.

Both sides must agree on roles for full bidirectional protection. This creates a partial security window during migration. Networks connecting to regions with low AI adoption in automation tools may experience slower rollout kinetics due to manual configuration bottlenecks. While internal architectures often prioritize iBGP stability, external perimeters require this explicit signaling to prevent accidental route propagation. The cost of implementation is negligible compared to the operational overhead of managing unwieldy prefix lists that fail to detect subtle leaks. This single configuration step eliminates the need for massive static filters while providing immediate leak containment.

Operational Checklist for Maximum Prefix Limits and ROV Rejection

Imposing maximum prefix limits detects session anomalies when a peer announces 100x or 1000x their normal route count. This mechanical threshold acts as a circuit breaker against volumetric route leaks before they propagate deeper into the topology. Operators configuring eBGP sessions must pair these limits with strict RPKI-ROV rejection policies to block cryptographically invalid origins. The RPKI-To-Router protocol efficiently distributes these validation states, unlike legacy scripts that struggle with scale.

1. Configure hard ceiling thresholds on every external neighbor interface.
2. Enable automatic session teardown upon exceeding the set limit.
3. Apply ROV-invalid drop actions to the inbound policy chain.
4. Signal roles using the RFC 9234 OTC attribute for leak containment.

Rigid rejection has a cost: false positives occur during legitimate renumbering events if validation data lags. Infrastructure logistics currently consume 40% of revenue, creating pressure to automate these checks rather than manage manual filters. Networks ignoring this shift face rising operational burdens as AI-Ready Infrastructure demands tighter convergence times.

Operationalizing RFC 9234 and Peerlock for Leak Prevention

RFC 9234 OTC Attribute and Gao-Rexford Role Agreement

RFC 9234 defines BGP OPEN Roles using the OTC attribute to enforce role agreement without IRR or RPKI data.

This mechanism requires both sides of an eBGP session to explicitly agree on their relationship within the Gao-Rexford model before exchanging routes. Operators must configure the specific role type in the session setup. This binds the policy to the TCP connection on port 179 rather than external databases. The OTC attribute signals whether a peer acts as a customer, provider, or peer. Routers instantly reject paths that violate directional rules. This approach eliminates the latency associated with downloading massive filter lists from questionable provenance sources.

1. Define the local role (customer, provider, peer) in the neighbor configuration block.
2. Enable the OTC attribute transmission in the BGP session capabilities.
3. Set the policy to drop updates where the received role contradicts the local expectation.

Strict bilateral dependency is the limitation. A single non-compliant peer forces the operator to revert to permissive acceptance for that specific link. Unlike cryptographic validation, this method offers immediate protection against configuration drift without waiting for global RIR synchronization.

Configuring Peerlock-Lite Filters and Maximum Prefix Limits

Automatic session termination addresses route leaks identified as Issue C by enforcing hard ceilings on announced routes.

Operators must define maximum prefix limits that trigger a teardown when a peer announces 100x or 1000x their normal volume. This mechanical threshold acts as a circuit breaker before anomalous traffic propagates through the eBGP topology. The configuration requires setting a strict count per neighbor, ensuring the router rejects excess prefixes immediately without human intervention.

1. Calculate baseline route counts for every external neighbor based on historical data.
2. Apply a multiplier threshold to establish the hard ceiling for each session.
3. Enable the automatic shutdown feature to sever the TCP session upon violation.

4.

Job Snijders recommended using the RFC 9234 OTC attribute and optionally using Peerlock for perimeter defense. Full Peerlock blocks specific ASNs from appearing anywhere in the AS path behind assigned sessions. This offers granular control against unauthorized transits. Peerlock-lite simplifies this by focusing only on immediate neighbors. It reduces configuration overhead but misses deeper path anomalies. Operators managing global tech solutions often prefer the full variant when peering with complex multi-hop topologies where indirect leaks pose higher risks.

1. Identify ASNs that must never appear behind specific customer or peer sessions.
2. Apply the full filter set if the router supports deep path inspection capabilities.
3. Deploy the lite variant where vendor hardware limits processing power for long lists.

Full Peerlock costs maintenance. Every new peer requires manual updates to the block list, creating a lag in protection during rapid expansion. Peerlock-lite sacrifices depth for speed, leaving networks vulnerable to leaks originating two hops away. Teams must choose between thorough coverage and operational agility based on specific topology constraints. Teams implementing these filters often reference enterprise routing distinctions to determine whether their internal mesh can tolerate the latency of deep packet inspection.

NANOG 96 concluded on February 4, 2026, with a direct mandate to sunset IRR-based prefix-lists due to their inability to validate path authorization. Job Snijders declared that legacy filters function as expensive allow any any rules, creating fragile perimeters vulnerable to mis-originations and unauthorized more-specifics.

Adoption of ASPA and RFC 9234 accelerates as enterprises face implementation hurdles. 79% of organizations struggle to translate strategic deployment into value without strong data foundations. Technology sectors lead this shift at a 94% implementation rate, proving that automated validation scales improved than manual IRR maintenance. However, ASPA adoption demands RIR publication of upstream lists. Many tier-2 ASes currently skip this step, leaving the AS path unsigned. Failure to align with these standards leaves operators exposed to route leaks that modern OTC attribute signaling would otherwise prevent automatically.

Executing the Transition with OpenBGPD Role Configuration

OpenBGPD enables simultaneous ASPA validation and RFC 9234 signaling via a single `role` keyword. This eliminates manual filter recursion.

Operators configure the session type directly, binding policy to the TCP connection rather than external databases. This approach removes dependency on unwieldy formats that historically plagued perimeter security. The OTC attribute signals peer relationships instantly. Routers reject paths violating directional rules without consulting IRR objects. Configuration complexity drops because frequently changing parts provision through the RTR protocol instead of static lists.

Strict bilateral requirement is the limitation. Both sides must agree on roles within the Gao-Rexford model for full effect. However, opportunistic deployment still blocks leaks even when intermediate networks lack support. Fastly resolved configuration errors using this attribute despite limited global adoption. The cost of delay remains high as legacy methods consume engineering hours improved spent on automation. Network infrastructure logistics expenses are projected to fall significantly by 2030, rewarding those who automate now. Manual prefix management cannot compete with the speed of cryptographic verification pipelines.

A vast North American BGP market stands against route leaks. The shift from fragile allow-lists to cryptographic enforcement prevents unauthorized more-specifics before they propagate. Operators gain durability against mis-originations without maintaining massive prefix tables.

Legacy IRR Provenance Risks Versus RTR-Provisioned Stability

IRR datasets force single prefix mappings per ASN. This prevents granular neighbor policies that modern peering requires. This architectural rigidity creates unwieldy formats that operators struggle to maintain as session counts swell into the thousands. Constructing filters from these sources often yields incomplete allowlists because route objects cannot specify prefix-length ranges without manual duplication. The resulting configuration bloat increases the risk of human error during updates. This directly contradicts industry standards that mandate strict default-deny postures.

RTR-provisioned stability replaces static text files with flexible binary streams. It separates stable policy from volatile route data. This shift eliminates the need to upload megabytes of text during every change window, reducing operational friction significantly. Network teams observing this transition report concise configurations where frequently changing parts provision automatically through the RTR protocol.

The hidden cost of legacy filters extends beyond labor. Routers consume excessive TCAM space processing redundant entries generated by recursive AS-SET expansion. Operators clinging to these methods face rising complexity as infrastructure logistics costs consume a significant portion of operating budgets. InterLIR recommends sunsetting these fragile lists immediately to prevent route leaks caused by outdated or inaccurate community submissions. The initial coordination required to publish ROAs is real, yet the long-term gain is a self-healing perimeter that rejects invalid paths without manual intervention.
